Neff D65XAM2S0B, Integrated Design Hood

Contact Us for availability
- ColourBlack
- Energy RatingB
- Installation TypeBuilt-In

- 60 cm wide
- Installation: Cupboard 60 cm
- Suitable for ducted extraction and recirculation
- For recirculated extraction various recirculation kits are available as optional accessories.
- Flush-fitted installation for a seamless integration in wall cupboards.
- Space efficient compact design for extra storage possibilities on the hood, up to max. 10 kg storage weight per side.
- Glass panel with touch control for an easy operation and enhanced vapor capture.
- Extraction and lighting are automatically turned on and off by opening and closing the glass panel.
- Lighting can also be turned on and off when the glass panel is closed by quick hand touch on control panel.
- Includes mats for hood storage areas, protectioning against scratches and to help prevent items moving in this space.
- Electronic controls via Touch control
- 3 speeds plus intensive
- SoftLight with dimmer function
- 2 x 2 W LED lights
- Colour Temperature: 3500 K
- Light Intensity: 451 lux
- Automatic revert setting
- Automatic intensive revert (6mins)
- Stainless steel filter covers
- 2 metal grease filter cassettes
- Easy to clean smooth surfaces and materials.
- Extraction rate according to EN 61591 ø 15 cm:
- max. Normal use460m³/h
- Intensive749 m³/h
- Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
- Max. normal use:63dB(A) re 1 pW
- Intensive:73 dB(A) re 1 pW
- Noise max. Normal Level: Noise, max. speed in normal us: 63 dB dB*
- With the Clean Air Plus recirculation kit (available as optional accessory) your appliances reaches:
- Extraction rate in recirculation mode: Max. normal use:451m³/h
- Intensive:652m³/h
- Noise level in recirculation mode: Max. normal use:67dB(A) re 1 pW
- Intensive:74 dB(A) re 1 pW
- Installation system: IDH comfort installation
- Suitable for installation in bottomless wall cupboards.
- Enclosed spacers for installation in wall cupboards with maximum depth of up to 360mm.
- For installation in higher wall cupboards chimney extensions are available as optional accessories.
- Chimney extensions are compatible with the available recirculation kits.
- Dimensions (HxWxD): 340 x 597 x 298 mm
- Built-in dimensions (HxWxD): 340 x 560 x 300 mm
- Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
- Back-pressure flap: Yes
- Electrical cable length 1.3 m
- Please reference the built-in dimensions provided in the installation drawings
- Energy Efficiency Class: B (at a range of energy efficiency classes from A+++ to D)
- Average Energy Consumption: 62.7 kWh/year*
- Blower Efficiency Class: B*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: B*
- Power rating: 256 W
Manufacturer | Neff |
---|---|
GTIN | 4242004260080 |
Colour | Black |
Model Number | D65XAM2S0B |
Block eCommerce | No |
Price | £549.95 |
Number of Lights | 2 |
Warranty Duration | 2 |
Noise Level | 63 |
Plug Type | GB plug |
Cord Length | 130 |
Min Niche Width | 560 |
Max Niche Width | 560 |
Typology | Built-in/Built-under |
Installation Type | Built-In |
Operating Mode | Convertible |
Motor Location | Integrated motor in hood body |
Fluid Dynamic Efficiency | 27.6 |
Fluid Dynamic Efficiency Class | B |
Lighting Efficiency | 71.6 |
Lighting Efficiency Class | A |
Grease Filtering Efficiency | 90.2 |
Grease Filtering Efficiency Class | B |
Max Air Flow | 460 |
Min Air Flow | 265 |
Air Flow Boost | 749.0 |
Sound Power Max Speed | 63 |
Sound Power Min Speed | 50 |
Sound Power Boost | 73 |
Noise Level Boost Position | 73 |
Max Output Air Extraction | 460 |
Boost Position Air Extraction | 749 |
Max Output Recirculating Air | 451 |
Boost Position Output Recirculating | 652 |
Grease Filter Material | Washable stainless steel |
Height without Chimney | 60 |
Number of Motors | 1 |
No Return Air Flow Flap | Yes |
Grease Filter Type | Kassette |
Niche Depth | 300 |
Approval Certificates | CE, E17D UKCA marking, VDE |
Appliance Frequency (Hz) | 50 |
Appliance Voltage (V) | 220-240 |
Construction Type | Built-In |
Type of Control Settings | LED;touch control |
Type of Control / Appliances | Electronic |
Is On Display | false |
Is Soft Bundle | No |
Energy Rating | B |
